High Quality Etching Glass by Automatic Cutter
Product performance
The design draws on the concept of German Industry 4.0, and realizes the automatic cutting process, information data and intelligent operation. The overall frame of the equipment adopts bridge steel technology, which is aged after welding, and the fuselage steel plate is milled out with a gantry mill, which has super strength and stability qualitative. Frame structure material is made of high manganese steel, high strength, no deformation, welding after aging treatment, good physical properties can be matched with bilateral grinding, four-edge grinding line production, glass does not fall, improve work efficiency.
Product performance
The layout attracts on the thought of German Industry 4.0, and realizes the computerized slicing process, records statistics and shrewd operation. The usual body of the gear adopts bridge metal technology, which is aged after welding, and the fuselage metal plate is milled out with a gantry mill, which has superb electricity and balance qualitative. Frame shape fabric is made of excessive manganese steel, excessive strength, no deformation, welding after getting older treatment, true bodily homes can be matched with bilateral grinding, four-edge grinding line production, glass does no longer fall, enhance work efficiency.
Technical Details:
Model | Cutting accuracy | Speed | Max cutting size | Cutting Thickness | Power | Power Supply |
6133 | ≤±0.20mm/m | 0-220m/min | 6100mm×3700mm | 3-19mm | 25kw | 380v/50HZ |
5133 | ≤±0.20mm/m | 0-220m/min | 5100mm×3300mm | 3-19mm | 25kw | 380v/50HZ |
4228 | ≤±0.20mm/m | 0-220m/min | 4200mm×2800mm | 3-19mm | 18kw | 380v/50HZ |
2621 | ≤±0.20mm/m | 0-220m/min | 2600mm×2100mm | 3-19mm | 12kw | 380v/50HZ |
Remark :Special sizes can be customized |
Company Introduction
As a well-known Chinese brand, Huayuexing has created a professional team with responsibility and professionalism in technology, marketing and after-sales since its establishment. With professional ability and service spirit, based on the needs of the industry, to provide customers with stable performance, advanced technology processing equipment.
